| HEC-D4 Series |
|
Publish Time：2012/7/25 | Click：1068
|
|
Electrical characteristics ：Type | HEC400-D4 | HEC500-D4 | HEC600-D4 | HEC800-D4 | HEC1000-D4 | Rated Current | ± 400A | ±500A | ±600A | ±800A | ±1000A | Output Current | ±80mA | ±100mA | ±120mA | ±160mA | ±200mA | | Linear Range | 1.5 times of the maximum of measuring range | Accuracy | 0.5% | | Degree of Linearity | 0.1% | Turn Ratio | 1:5000 | Offset Current | ±0.2mA | Hysteresis Error | ±0.1mA | Temperature Drift | 0.025%/ ℃ | Response Time | ＜ 1μS di/dt=100A/μS | Power Supply | ± 12V 、± 15V 、± 24V （± 5% ） | Current Consumption | ±28mA plus output current | Isolation | 3KV AC 50Hz/min | Operating Temperature Range |
-10 ℃ ～ +80 ℃
| Storage Temperature Range |
-25 ℃ ～ +85 ℃
|

|
| |
|
|
|
